KROHNE OPTIFLUX 2000 EN - Manual (Page 42)

6
TECHNICAL DATA
42
OPTIFLUX 2000
www.krohne.com 4/2014 - 4000839504 - HB OPTIFLUX 2000 R04 en
ASME B16.5 / 150 lb flanges
ASME B16.5 / 300 lb flanges
Nominal size
[inches]
Dimensions [inches] Approx. weight
[lb]
L H W
1" 5.91 5.39 4.25 7
1½" 5.91 6.10 5.00 11
2" 7.87 7.05 5.98 18
3" 7.87 8.03 7.50 26
4" 9.84 9.49 9.00 44
5" 9.84 10.55 10.00 49
6" 11.81 11.69 11.00 64
8" 13.78 14.25 13.50 95
10" 15.75 16.30 16.00 143
12" 19.69 18.78 19.00 207
14" 27.56 20.67 21.00 284
16" 31.50 22.95 23.50 364
18" 31.50 24.72 25.00 410
20" 31.50 26.97 27.50 492
24" 31.50 31.38 32.00 675
Nominal size
[inches]
Dimensions [inches] Approx. weight
[lb]
L H W
1" 5.91 5.71 4.87 11
1½" 7.87 6.65 6.13 13
2" 9.84 7.32 6.50 22
3" 9.84 8.43 8.25 31
4" 11.81 10.00 10.00 44
6" 12.60 12.44 12.50 73
8" 15.75 15.04 15.00 157
10" 19.69 17.05 17.50 247
12" 23.62 20.00 20.50 375
14" 27.56 21.65 23.00 474
16" 31.50 23.98 25.50 639
20" 31.50 28.46 30.50 937
24" 31.50 33.39 36.00 1345
