5
PROFIBUS SETTINGS
34
MFC 300
www.krohne.com 07/2014 - 4001086802 - AD MFC 300 PROFIBUS R02 en
Detailed description of special settings concerning the PROFIBUS features easily operated via
the local display menu of the signal converter (refer to the following sections). For a detailed
description of the menus and functions in general please refer to the standard product
documentation of the signal converter.
5.1 Menu A, Quick Setup
5.2 Menu B, Test
No. Function Settings / descriptions
A2 Tag
A2 Tag Tag descriptor of the physical block of the PROFIBUS module will be
displayed. The Tag descriptor provides an application specific reference to
the blocks. It will be assigned by the user of the device. The Tag descriptor is
an octet string (a visible string will be preferred) consisting of 32 byte. The
first 21 characters will be displayed only!
A3 Reset
A3 Reset -
A3.1 Reset Errors This menu function can be used to reset all errors that are not removed
automatically (power fail, totaliser overflow)
Reset? Select: no / yes
No: Exit the function.
Yes: Resets the errors and exits the function.
The following reset menus for the totaliser are only available, if the quick access has been activated in the menu "Setup
> Device > Quick Setup". Each totaliser can be activated for quick access independently.
A3.2 FB4 totaliser 1 For PROFIBUS devices: The totaliser can be reset to zero in this menu.
A3.3 FB5 totaliser 2
A3.4 FB6 totaliser 3
A4 Station Address
A4 Station Address Selects the address of the device at the PROFIBUS interface.
The PROFIBUS address can also be changed using the PROFIBUS service
"set_slave_add". The input range is 0...125 according to the PROFIBUS
specification. Address 126 is the default address and cannot be set via the
PROFIBUS service "set_slave_add" - use menu instead to reset to default
address.
No. Function Settings / descriptions
B3 Information
B3.5 PROFIBUS Available if there is a PROFIBUS interface in existence; displays the
following mentioned information about the PROFIBUS interface:
Ident No. / software revision no. of the PROFIBUS software / production date
