APPLICATION PROFILE
4
33
MFC 300
www.krohne.com 07/2014 - 4001086802 - AD MFC 300 PROFIBUS R02 en
4 0 S - Sensor Signal Error X X
1 S - Excessive Noise X X
2 S - External Vibration X X
3 S - Sensor Levels X X
4 S - Temperature Drift X X
5 S - Tube Asymmetry X X
6 S - System control X X
7 S - SE PCB Temperature X X
5 0 S - Tube Temperature X X
1 S - Density X X
2 S - Startup X X
3 S - Power Fail X X
4 S - Resistor Circuit Defective X X
5 S - SE Defective X X
6 S - 2 Phase Flow X X
7 S - Density Calib. Failed X X
6 0 S - BE PCB Temperature X X
1 S - Interface PCB Fault X X
2 Reserved
3 Reserved
4 Reserved
5 Reserved
6 C - Zero Calibration X
7 C - Standby Mode X
DIAGNOSIS_EXTENSION DIAGNOSIS
1 2 3 ... 4
0 1 2 3 4 5 6 7 0 1 2 3 4 5 6 7 0 ... 6 7
Octet number Bit number Subparameter DIA_HW_ELECTR DIA_HW_MECH DIA_TE
MP_M
OTOR
DIA_TE
MP_E
LE
CT
R
DIA_MEM_CHKSUM DIA_MEASUREMEN
T
DIA_NOT_IN
IT
DIA_INIT
_ERR
DIA_ZERO_ERR DIA_SUPP
LY
DIA_CON
F
_INVAL
DIA_WARMSTART DIA_COLDSTART DIA_M
AINTENANCE
DIA_CHARACT IDEN
T_NU
MB
ER_Vio
la
tion
Reserved ..
.
Reserved EXTEN
S
ION_AVAILABLE
X :Ext_Diag (Bit 3 of Station_Status_1) will be set too!
X :Corresponding DIAGNOSIS bits is set to 1 if status occured
