APPLICATION PROFILE
4
31
MFC 300
www.krohne.com 07/2014 - 4001086802 - AD MFC 300 PROFIBUS R02 en
*: for a more detailed description of the above-mentioned subparameters please check the
signal converter handbook (section: Status messages and diagnostic information)
(F): Device Error (F): Device Error (F): Device Error (F): Device Error
(F): Application Error
(S): Uncertain measurement / measurement out of specification
(C): Simulation of the measured value
(I): Information
4.3.4 Mapping of DIAGNOSIS_EXTENSION bits into DIAGNOSIS bits
How to read this table:
If e.g. an S - Temperature Drift error has been detected the below-mentioned
DIAGNOSIS_EXTENSION bits will be set:
• DIAGNOSIS_EXTENSION (Octet 1 / Bit 2): S - Out Of Specification
• DIAGNOSIS_EXTENSION (Octet 4 / Bit 4): S - Temperature Drift
These bits will be mapped to the below-mentioned DIAGNOSIS bits (which will be set
additionally):
• DIAGNOSIS (Octet 2 / Bit 5): DIA_MAINTENANCE
• DIAGNOSIS (Octet 4 / Bit 7): EXTENSION_AVAILABLE
5 0 S - Tube Temperature Temperature is exceeding limits
1 S - Density Process density is over range
2 S - Startup The device is in startup mode
3 S - Power Fail Device has been powered up
4 S - Resistor Circuit Defective Temperature and strain measurement defective
5 S - SE Defective "Operational fault in sensor electronics"
6 S - 2 Phase Flow 2 phase signal is above the programmed threshold
7 S - Density Calib. Failed Density calibration failed
6 0 S - BE PCB Temperature Temperature on BE PCB is exceeding maximum limit
1 S - Interface PCB Fault Error detected during self-monitoring of interface card
2 Reserved
3 Reserved
4 Reserved
5 Reserved
6 C - Zero Calibration Zero calibration performed
7 C - Standby Mode Device is in standby mode
Octet num
b
er
Bit
number
Subparameter Comment*
