4
APPLICATION PROFILE
30
MFC 300
www.krohne.com 07/2014 - 4001086802 - AD MFC 300 PROFIBUS R02 en
4.3.3 DIAGNOSIS_EXTENSION
Octet numb
er
Bit number Subpar
ameter
Comment*
1 0 F - Device Error F - Device Error F - Device Error F - Device Error Fatal device error - general info
1 F - Application Error Fatal application error - general info
2 S - Out Of Specification Uncertain Measurement - general info
3 C - Checks In Progress Test function activated - general info
4 Parameter (DM) Parameter error - general info
5 Display Display error - general info
6 Sensor Electronic (ADC) Sensor error - general info
7 IO 1 IO1 error - general info
2 0 IO 2 IO2 error - general info
1 Output A Output A (Puls / Current) error - general info
2 Output B Output B (Puls / Current) error - general info
3 Fieldbus Fieldbus module error - general info
4 F - No Device Communication Internal Communication failure
5 F - Parameter Update Error F - Parameter Update Error F - Parameter Update Error F - Parameter Update Error Parameter requested not available
6 I - Power Fail Device has been powered up
7 I - Write Cycles Overflow Too much write cycles occured
3 0 Reserved
1 F - Sensor Exceeding Limit Mass flow is greater than max. flowrate
2 F - Tube Not Oscillating Measurement tube is not oscillating
3 F - System Control System control generated an application error
4 F - Stop Mode Sensor is switched off
5 F - SE System Error Sensor error
6 F - SE Comms. Failure Communication error with sensor electronics
7 Reserved
4 0 S - Sensor Signal Error Drive signal is switched off due to sensor signals
1 S - Excessive Noise (for future use only)
2 S - External Vibration (for future use only)
3 S - Sensor Levels Oscillation amplitude of sensor A or sensor B to low
4 S - Temperature Drift (for future use only)
5 S - Tube Asymmetry (for future use only)
6 S - System control System control caused "out of spec" flag
7 S - SE PCB Temperature Temperature on SE PCB is exceeding maximum limit
