Definition of totalizer functions
INFORMATION!
During network configuration the user has to define which function block outputs of the signal
converter should be transferred cyclically to the master. This is performed by a bus
configuration tool (e.g. "HW- Config" for PC-S7 from Siemens). This tool offers specific functions
as follows:
1. It is possible to configure an "Empty" block (the code of an "Empty" block is defined as 0x00) on
each block number. This implies: no data are transmitted in the cyclic data telegram for this
block.
2. There is NO "Totaliser (TOT)" function block allowed on block position 1, 2, 3, 7, 8, 9, 10 and 11!
On these positions, only an "Analog Input (AI)" function block or an "Empty" block is allowed!
(Note: All codes supported by "Analog Input (AI)" - and "Totaliser (TOT)"
– function blocks will
be found in the corresponding GSD files.)
3. There is NO "Analog Input (AI)" function block allowed on block position 4, 5 and 6! On these
positions, only a "Totaliser (TOT)" function block or an "Empty" block is allowed!
4. There is a choice of 7 different totaliser functions, which can be allocated to the blocks 4, 5
and/or 6.
Total cyclic transfer of the totalizer value with status to the master
SetTot + Total cyclic transfer of the totalizer value with status to the master + cyclic
control data from master to the device via the parameter SetTot
ModeTot + Total cyclic transfer of the totalizer value with status to the master + cyclic
control data from master to the device via the parameter ModeTot
SetTot + ModeTot + Total cyclic transfer of the totalizer value with status to the master + cyclic
control data from master to the device via the parameters SetTot and
ModeTot (in the given order)
SetTot cyclic control data from master to the device via the parameter
SetTot
ModeTot cyclic control data from master to the device via the parameter
ModeTot
SetTot + ModeTot cyclic control data from master to the device via the parameters
SetTot and ModeTot (in the given order)
