Page 31
31
5xxxx
6xxxx
7xxxx
8xxxx
9xxxx
Axxxx
Byte
Bxxxx
Double (Word swapped)
6.5
Register Addresses
Address
Description
Units/Value
Access
Menu Ref.
Hex(Decimal) Bit registers
0000/0000
Update configuration data
Save changes in
EEPROM
R/W
0001/0001
Begin zero flow calibration
-
R/W
3.1.1
0002/0002
Reset totals
-
R/W
0003/0003
Switch to standby mode
-
R/W
3.1.4
0004/0004
Switch to measure mode
-
R/W
3.1.4
Float registers
0010/0016
Mass flow rate
g/s
R
0011/0017
Volume flow rate
cm
3
/s
R
0012/0018
Volume total
cm
3
R
0013/0019
% volume flow rate
%
R
0014/0020
% mass flow rate
%
R
0015/0021
Solid flow rate
g/s
R
0016/0022
Density
g/cm
3
R
0017/0023
Referred density
g/cm
3
R
0018/0024
Solute density
g/cm
3
R
3.10.1
0019/0025
Solute k1 constant
g/cm
3
/
°
C
RW
3.10.2
001A/0026
Solute k2 constant
g/cm
3
/
°
C
2
RW
3.10.3
001B/0027
Liquid density
g/cm
3
RW
3.10.4
001C/0028
Liquid k1 constant
g/cm
3
/
°
C
RW
3.10.5
001D/0029
Liquid k2 constant
g/cm
3
/
°
C
2
RW
3.10.6
001E/0030
Reference temperature
x10
°
C
RW
001F/0031
Reference density slope
-
RW
0020/0032
Fixed density
g/cm
3
RW
0021/0033
Head constant
-
R
3.1.6
0022/0034
(G) Density coefficient CF1
(P&E) Water calibration
reference frequency
-
50-200 Hz
R
R
3.9.1
3.9.1
0023/0035
(G) Density coefficient CF2
(P&E) Air calibration
reference frequency
-
50-200 Hz
R
R
3.9.2
3.10.3.
0024/0036
(G) Reference strain CF3
(P&E) Temperature constant
-
R
R
3.9.3
0025/0037
(G) Reference Temp. CF4
(P&E) Frequency constant
-
R
R
3.9.4
0026/0038
Zero flow cutoff
% of nominal
R
3.1.2
0027/0039
Low flow threshold
% of full scale x 10
RW
3.1.1
0028/0040
Frequency
Hz
R
2.7.3
0029/0041
Maximum trigger value
as base unit
RW
3.7.4
002A/0042
Minimum trigger value
as base unit
RW
3.7.3
Integer registers
003C/0060
Measurement time-constant
x10 s
R/W
3.1.3
003D/0061
Drive level
-
R
003E/0062
Strain
ohms x 20
R
