6.3 Data Formats
Table 2. Integers
Bits
15-8 High byte
7-0 Low byte
Table 3. Single Precision Floating Point.
Bits Bit order
MSB - LSB Mnemonic
Bits 32-24 SEEEEEEE S/E
Bits 23-16 EMMMMMMM E/M1
Bits 15-8 MMMMMMMM M2
Bits 7-0 MMMMMMMM M3
Table 4. Double precision floating Point.
Bits Bit order
MSB - LSB Mnemonic
Bits 63-56 SEEEEEEE S/E
Bits 55-48 EEEEMMMM E/M1
Bits 47-40 MMMMMMMM M2
Bits 39-32 MMMMMMMM M3
Bits 32-24 MMMMMMMM M4
Bits 23-16 MMMMMMMM M5
Bits 15-8 MMMMMMMM M6
Bits 7-0 MMMMMMMM M7
S = sign bit E = exponent M = mantissa
Table 5. Transmission Order
Transmission
order/type 1st
byte
Last
byte
Bits see
4.2.1
Bytes 0 Low
Integers High Low
Float M2 M1 S/E E/M1
Double M6 M7 M4 M5 M2 M3 S/E E/M1
6.4 Addresses Allocation
The following table shows the supported data types and their address block allocation
Address Range Type
0xxxx Bit (Descrete Outputs)
1xxxx
2xxxx
Float (Word swapped)
3xxxx Integer (Input Registers)
4xxxx
