7
TECHNICAL DATA
44
OPTISENS CL 1100
www.krohne.com 01/2012 - 4001834501 - MA OPTISENS CL 1100 R01 en
Operating conditions
Temperature
operating
-5…+70°C / +23…+158°F
Max. operating
pressure
6 bar / 87 psi
Min. flow rate > 30 l/h (7.93 gal/H)
Min. conductivity > 150 μS/cm (with ASR: >
200 μS/cm
> 150 μS/cm
Materials
Electrode shaft Glass
Measuring electrodes Gold
Reference electrode Ag / Ag / Tepox gel
Diaphragm Ceramics
Gasket EPDM
Electrical connection
Connector M12
Cable Cable CL-W 1100
Cable design Shielded cable with M12 connector and core end sleeves
Length 5 m / 16.4 ft or 10 m / 32.8 ft
