After starting-up the signal converter, the measuring screen appears. This is the standard
screen which is displayed automatically in the normal operating mode. If you are in this mode
and you want to adjust the temperature compensation, you have to perform the following steps:
Step 1: activating the temperature compensation for measurement
Press ^ ^ ^ ^ several time until you reach the measuring mode again. Choose yes yes yes yes to safe and confirm
your selection.
Press >>>> for more than 2.5 seconds, then release the button. You are now on the main menu level. In the
upper line on the right side of the display "A" appears, beneath the main menu quick setup quick setup quick setup quick setup is highlighted.
Press or until the main menu setup setup setup setup is highlighted.
MAIN MENU
A quick setup
B test
> C setup > C setup > C setup > C setup
D service
Press >>>> to enter the chosen menu.
You are on the first submenu level. In the upper line of the display "setup" and "C1"
appears, beneath the submenu process input A process input A process input A process input A is highlighted.
Press >>>> to enter the chosen menu.
You are on the second submenu level. In the submenu parameter parameter parameter parameter
(Cl
2
/ClO
2
/O
3
) is highlighted.
Use or until the submenu temperature temperature temperature temperature is highlighted.
Press >>>> to enter the chosen menu.
You are on the parameter level. In the upper line of the display
"temperature" and "C1.15.1" or "C2.15.1"appears, beneath the option
probe probe probe probe is highlighted.
Use or until the menu item temp. comp. temp. comp. temp. comp. temp. comp. is highlighted.
Press >>>> to enter the chosen menu.
Now you can set up the temperature compensation.
Press or to choose between linear linear linear linear and off off off off.
Pres ^ ^ ^ ^ to confirm the entered value.
If you have chosen the option linear, you can select the type of
temperature compensation now.
Press or until menu item temp.coefficient temp.coefficient temp.coefficient temp.coefficient is highlighted.
Enter the value and press ^ ^ ^ ^ to confirm the value.
Press or to choose probe probe probe probe.
Press >>>> to enter the chosen menu.
Press or to choose between Pt1000, Pt100 or
manual.
Press ^ ^ ^ ^ to confirm the entered value.
