TECHNICAL DATA

48

OPTISENS PH 8100

www.krohne.com

03/2012 - 4001925901 MA OPTISENS PH 8100 R01 en

Figure 6-6: Dimensions SENSOFIT IMM 1000

Dimensions [mm]

Dimensions [inch]

a

1030 (may be shortened)

40.55 (may be shortened)

b

160

6.3

c

100

3.94

d

Ш 25

Ш 0.98

e

Ш 59

Ш 2.32
