PAR. 3.3.7, After 2nd paragraph “To change the default settings . . . abort the change.” add new paragraph:
To change the power-up default settings to use different positive and negative limits, first set the bipolar levels as
described above. Then refer to PAR. 3.3.3.1 and set the independent limits as desired. When complete, press
$
to save for power-up.
PAR’s. 3.3.9.7 and 3.3.9.8, refer to Table 3-11; modify the TYPE setting as shown below:
PAR. 3.6.3.4, 1st paragraph Change FROM: “126 different dwell times” TO: “122 different dwell times”
PAR. 3.6.3.4, 2nd paragraph Change FROM: “126 different segments” TO: “122 different segments”
Table 3-9: Sine, Triangle and Ramp Waveform Frequency vs. Points
Change: FROM: Frequency FROM: 0.01
TO: Frequency FROM: 0.01 (0.001 sine and triangle)
Table 3-11: Waveform Segment Details Menu
Change: FROM: Sine or Triangle: 0.01 to 443 Hz
TO: Sine or Triangle: 0.001 to 443 Hz
APPENDIX A, PAR. A.6
*IDN? query
APPENDIX B
The following commands/queries are added to Appendix B.
B.33.1 [SOURce:]LIST:REPeat COMMAND
LIST:REP
Syntax: Short Form: LIST:REP ,,
Long Form: LIST:REPeat ,,
Waveform Stop
Note: Accessed by
pressing F3 (Dis-
play) from the power
up screen. Output Off When waveform is stopped (e. g., by pressing F5), output freezes at whatever
level the waveform was at when F5 was pressed, then after a brief delay output
is set to STANDBY (disabled).
Last Level When waveform is stopped (e. g., by pressing F5), waveform runs through full
cycle. The output stops at the last generated value of the waveform (e.g., for a
sinewave segment of 0° to 270°, 10V amplitude, 0V offset, when F5 is pressed
the output will end up at -10V.
Current lvl When waveform is stopped (e. g., by pressing F5), output freezes at whatever
level the waveform was at when F5 was pressed.
REMOTE
DEBUG OFF
ON
OFF - LCD does not show programmed settings for main and protection chan-
nels while in remote mode of operation (local mode is unaffected).
ON - Programmed settings for main and protection channels are displayed,
however the unit responds more slowly.
SETTING CHOICES FUNCTION
TYPE Trigger Determines whether high level, low level or high-to-low edge is required at trigger
port to allow waveform to continue. NOTE: Offset does not affect trigger, 0V offset
is recommended.
