KEPCO, INC. " 131-38 SANFORD AVENUE " FLUSHING, NY. 11352 U.S.A. " TEL (718) 461-7000 " FAX (718) 767-1102
http://www.kepcopower.com " email: [email protected]
• Press the Initialize Card button
NOTE:
If initialization fails and an error message is displayed, repeat step 3, making sure that the
proper information is entered, and the new PROM was installed
FIGURE 3. VISA DRIVER START-UP.
FIGURE 4. BIT 4886 CARD INITIALIZATION
USING VISA DRIVER
5. After initialization, proceed to revised PAR. 3.3 to calibrate the upgraded unit.
4. BIT 4886 INSTRUCTION MANUAL CHANGES
A. ADD THE FOLLOWING INFORMATION TO TABLE 3-1.
TABLE 3-1. CALIBRATION MEASUREMENTS AND TOLERANCES - VOLTAGE
MODEL
LOW
RANGE
ZERO
VOLT
ZERO
MAX
OUTPUT
HIGH
RANGE
ACCURACY
LOW
RANGE
ACCURACY
LOW
RANGE
NOMINAL
VOLTAGE
LIMIT
ADJUST
PAR. 3.3.1
STEP 2
PAR. 3.3.1
STEP 3
PAR. 3.3.1
STEPS 4, 5
PAR. 3.3.1
STEPS 6, 8
PAR. 3.3.1
STEPS 11, 13
PAR. 3.3.1
STEP 10
PAR. 3.3.1
STEP 15
PAR. 3.3.2
STEP 4
PAR. 3.3.2
STEP 5
N/A
PAR. 3.3.2
STEPS 6, 7
PAR. 3.3.2
STEPS 8, 9
N/A
PAR. 3.3.2
STEP 3
BOP 100-4D-
4886-26810
0V
±0.001V
0V
±0.001V
104V
104.0075V (MAX)
-104.0075V (MIN)
±0.0075
26.003V (MAX)
-26.003V (MIN)
±0.002
26V
+104.0125V
±0.0125V
