I N S T R U C T I O N M A N U A L
KIT
KEPCO
KEPCO, INC. " 131-38 SANFORD AVENUE " FLUSHING, NY. 11352 U.S.A. " TEL (718) 461-7000 " FAX (718) 767-1102
http://www.kepcopower.com " email: [email protected]
An ISO 9001 Company.
219-0523
BIT 4886
FIRMWARE UPGRADE
1. DESCRIPTION
The Kepco KIT Model 219-0523 contains the firmware upgrade PROM to be installed in BIT 4886 Interface
Cards that have been previously installed in Kepco’s BOP 100-4D-4886 power supply. This firmware
upgrade allows the BOP 100-4D to be programmed to ±104V d-c.
This instruction sheet provides procedures for installing the new PROM, initializing the BIT 4886 card, and
updating the BIT 4886 manual with new information needed for calibrating the BOP power supply.
2. INSTALLATION OF UPGRADE PROM
A. MATERIAL REQUIRED (SEE TABLE 1.)
B. UPGRADE PROCEDURE
1. Remove a-c power to BOP by disconnecting line cord.
CAUTION: Take care not to damage ground strap connected to cover when removing cover. Ground
strap may be removed for convenience by removing attaching nut.
2. Remove BOP cover by removing 11 screws: (five from each side and one from the top (see Figure 1, Detail A).
3. Remove the BIT 4886 Interface card from the BOP as follows (See Figure 1):
NOTE:Numbers in circles of Figure 1 refer to numbered steps below:
Step 1. Unplug 3 pin Connector from Transformer at BIT 4886 Card, Location #3.
Step 2. Unplug Cable #2 (5-position connectors) from the BIT 4886 Interface Card.
Step 3. Unplug Cable #1 (18-position connectors) from the BIT 4886 Interface Card.
TABLE 1. MATERIAL REQUIRED
MATERIAL
LOCATION
QUANTITY
PROM
Not Supplied
4
Extractor
Provided in this Kit
1
ESD (Electrostatic Discharge) wrist strap.
Not Supplied
N/A
Phillips Screw Driver
Not Supplied
N/A
Sealant, Kepco P/N 201-0002
(Glyptol P/N 7526P, 7625R or 7625G or equivalent)
Not Supplied
N/A
Microsoft Windows-based computer with National Instruments VISA software installed
Not Supplied
N/A
Digital Voltmeter (capable of measuring 100.0005V
(Keithly 2010 multimeter or equivalent
Not Supplied
N/A
