6
HSF(A) 600W 101013
FIGURE 3. MECHANICAL OUTLINE DRAWING OF THE HSF A 600W POWER SUPPLY
3. FEATURES
3.1 DIP SWITCH CONFIGURATION
The HSF (A, AM) 600W Series incorporates two DIP switches, SW1 and SW2 (see Figure 4),
which must be configured before the unit is installed in the rack adapter. The DIP switch functions
are explained in Table 4.
1.500
[38.1]
0.093 [2.4]
14.667 [372.5]
5.
04
0
[1
28
.0
]
0.188 [4.8]
0.093 [2.4]
0.093
[2.4]
0.127
[3.2]
0.430 [10.9]
2.065
[52.5]
3.353
[85.2]
0.337 [8.5]
0.085 [2.2]
0.204 [5.2]
0.090 [2.3]
0.943 [23.9]
2.408 [61.2]
0.438 [11.1]
0.394
[10.0]
3.216 [81.7]
0.606 [15.4]
0.690 [17.5]
FRONT VIEW REAR VIEW
SEE
REAR
VIEW
SEE
FRONT
VIEW
NOTES:
1. MATERIAL:
A) BACKPLATE 0.064" THK. ALUM. 5052-H32
B) PCB 0.063" THK FR-4
C) FRONT PANEL 0.090 THK. ALUM. 6061-T6
2. FINISH:
FRONT PANEL -KEPCO DUAL TONE GRAY
3. MODULE IS KEYED AS SHOWN IN DETAIL
4. DIMENSIONS ARE IN INCHES, [DIMENSIONS IN BRACKETS
ARE IN MILLIMETERS].
3043321
15V 12V
= PIN PRESENT
= PIN MISSING
KEYING
DETAIL "A"
SEE DETAIL "A"
24V 28V 48V
AIRFLOW
5V
5.
21
8
[1
32
.5
]
4.288 [108.9]
