4 CA 400 060700
FIGURE 4. CA 400 INTERCONNECTIONS AND INPUT/OUTPUT PIN CONNECTIONS
Chassis Slide Kepco 108-0249
(Jonathan 110-QD-18-2)
(Not supplied)
Mounting Ear Bracket 128-1791 (Not supplied, 2 required per rack adapter)
Screw (mounting ear bracket to chassis) 101-0407 (6-32 x 3/16 St., FLPO) (Not supplied, 2 required per ear bracket)
Handle 139-0229 (Not supplied, 1 required per ear bracket)
Ferrule 170-0001 (Not supplied, 2 required per handle)
Screw (Handle to mounting ear bracket) 101-0396 (10-32 x 1/2 St., FLPO) (Not supplied, 2 required per handle)
Screw (Secure MST modules to chassis
for transportation purposes) 101-0406 (8-32 x 5/8 St. RHPH,
Thread cutting Type 23)
(Not supplied, 2 required per MST module)
TABLE 1. ACCESSORIES (CONTINUED)
ITEM PART NO. QUANTITY SUPPLIED
