22 System Introductions
Battery Pack
Item Specification
Vendor & model name Sanyo BTP-2231
Battery Type Li-Ion
Pack capacity 3200 mAH
Cell voltage 3.7 V
Number of battery call 8
Package configuration 2P4S
Package voltage 14.8V
DC-DC/Charger Board
Item Specification
Vendor & model name Ambit T62.120.C.00
Input voltage AC adapter: 19V-21V
Battery: 12V-16.8V
DC/DC converter output
Output rating CD-
5V 3.3V +12V 5V
SB Pri-
5V
SB
Current (w/load, A) 0~2 0~3.5 0~0.25 0.02 0~3.8
Charger output
Normal charge (charge while
system is not operative) 2.2A
Backgound charge (charge
even system is still
operative) 0.5A
Battery-lower 2 level (V) 14.1V
Battery-low 3 level (V) 12V
Protection
Charger protection Security timer control
Over temperature protection
Over voltage protection
DC/DC converter protection OVP (Over Voltage Protection, V)
OCP (Over Current Protection, A)
