3. Measurement Mode 19
Display Key Procedure
START/STOP
(5) ready will be displayed indicating that the instrument is ready
to start a measurement.
Press START/STOP key to start sampling.
☆ To go back to the measurement setting screen (a), press △
key.
[Start
Measuring]
(6)
(6-1)
Measuring at one point.
(6-2)
After measuring at one point is finished, move the probe to the next
point and press START/STOP key. Then measuring at the next point
will start.
★ Repeat the above procedure (6-1) and (6-2) for the configured
number of sampling points.
START/STOP
START/STOP ☆ To stop measuring halfway through: ▽ key.
- While sampling at a point, the sampling at the point will be
finished.
- When the instrument is waiting for the next sampling, the data
taken before the measurement stopped will be calculated.
☆ To stop a measurement (1) : △ key
- Will go back to the measurement standby mode (screen (b))
☆ To stop a measurement (2) : MENU key
- Will go back to the menu screen.
[Calculation
Result]
☆ PRINT: hardcopy of the display screen
☆ START/STOP or ▽: ready for measuring (to continue sampling)
☆ MENU: menu will be displayed.
NEXT START! --- waiting for sampling at the next point.
POINTS 001/016 --- No. of Points
setting value
No. of points where sampling has been done
8.100 m3/min
486.00 m3/hour
VEL 13.5 m/s
TEMP 126 ℃
Air volume (m³/m)
Air volume (m³/h)
Avg air velocity
Avg air temp
(b)
(6-1)
[Measurement Condition]
POINTS:
Set how many points to perform a measurement to find average air velocity?
Configurable number of partitions: 1 ~ 100 points
AREA(m²): Duct’s cross section area (Effective Area)
Configurable area size: 0.001∼9.999m²
* For S-TIME(S), DATA(N), MEMORY, PRINT, refer to page 15 describing the average
measurement.
< FLOW > ready
T: 00/10 M:036
N: 000/010 P:012
16.8 m/s
126 ℃
< FLOW >
T: 01/10 M:036
N: 001/010 P:012
16.8 m/s
127 ℃
< FLOW >
NEXT START !
POINTS 001/016
16.8 m/s
127 ℃
< FLOW >
T: 10/10 M:037
N: 001/010 P:012
16.8 m/s
126 ℃
