GUT-7700 USER MANUAL

1.Adopt the concept of FUZZY to design and press AUTO key to work out 90%

functions.

2.High-precision and stability test function.
3.Able to test OP, OPTO, REG, NE555 series and ULN2001 series.
4.Automatically power off or compel to power off to save the battery life.
5.Search OP, OPTO, REG, NE555 series and ULN2001 series Linear IC when

encounter an unknown IC.

6.Average search time: 0.8 seconds.
7.Equipped with empty-load test to shorten test time.
8.24pin IC textool, 16x1 LCD display, 5 function keys and 4x1.5V number 3 batter-

ies.

9.Able to search unknown linear IC.
10.Automatically search if there is any IC on the TEXTOOL or not after power on

and distinguish it.

11.If system error, it will power off automatically after 45 seconds to avoid consum-

ing the battery life.

III. FEATURE
