Installation, Introduction – Fire-Lite APS-6RF Auxiliary Power Supply User Manual
Page 11
APS-6RF Instruction PN 50893:B 7/20/00
11
2. Installation
WARNING: Use extreme caution when working with the APS-6RF.
High voltage and AC line-connected circuits are present. Turn off and
remove all power sources. To reduce the risk of electric shock make
sure to properly ground the unit.
Introduction
This section contains instructions for common wiring, configuring and
servicing the APS-6RF. For mounting and specific wiring instructions
refer to the appendix concerning your system.
Installation topics covered in detail:
!
Topic
Refer to...
Field Wiring
"Field Wiring an APS-6RF" on
page 12
Wiring Multiple APS-6RFs
"Connecting Multiple APS-6RF
Power Supplies" on page 13
Connecting to an IC-4F/ICE-4F
"Connecting the APS-6RF to an
IC-4F/ICE-4F Module" on page
14
Configuring
"Configuring the APS-6RF" on
page 15
Servicing
