ADTRAN NetVanta 5305 - Manual (Page 2)

ADTRAN, Inc.
International Department
901 Explorer Boulevard
Huntsville, Alabama 35806
USA
www.adtran.com/global
U.S. Headquarters
+1 256 963 8000
+1 256 963 6300 fax
[email protected]
International Customer Service
+1 256 963 8716 voice
Asia—Beijing, China
+86 10 8527 5011
+86 10 8527 5010 fax
[email protected]
Hong Kong
+852 3187 7111
+852 2116 4084 fax
[email protected]
Asia—Bangkok, Thailand
+66 2 625 3085
+66 2 625 3142 fax
[email protected]
Asia—Singapore
+65 6248 4665
+65 6320 8521 fax
[email protected]
Australia/New Zealand—
Melbourne, Australia
+61 3 9658 0501
+61 3 9658 0599 fax
[email protected]
Australia/New Zealand—
Sydney, Australia
+61 2 9959 2485
+61 2 9959 2244 fax
[email protected]
Canada—Montreal, Quebec
+1 877 923 8726
+1 514 989 3198 fax
[email protected]
Canada—Toronto, Ontario
+1 514 940 2888
+1 514 989 3198 fax
[email protected]
EMEA Regional Headquarters—
United Kingdom
+44 1256 884055
+44 1256 884056 fax
[email protected]
[email protected]
Mexico/Central America/
Caribbean—USA
+1 256 963 3113
+1 256 963 6300 fax
[email protected]
[email protected]
[email protected]
[email protected]
South America—USA
+1 954 474 4424
+1 954 474 1298 fax
[email protected]
[email protected]
[email protected]
ADTRAN is an ISO 9001, ISO 14001,
and a TL 9000 certified supplier.
Physical Interface
■ Six Wide Slots: Octal T1/E1, HSSI. and
Unchannelized T3
■ Dual LAN Ports: Auto-sensing 10/100Base-T
Ethernet Ports (RJ-45)
■ Console Port
Diagnostics LEDs
■ Power: 1 and 2
■ Slots: Status, Activity, Test
■ LANs: link, transmit, receive
Processor and Memory
■ 1 GHz, Motorola 7447
■ RAM: 256 MB
■ FLASH: 32 MB
Security
Firewall
■ Stateful Inspection Firewall
■ Denial of Service (DoS) Protection
■ Access Control Lists
■ Application Level Gateways (ALGs)
Network Address Translation
■ Basic NAT (1:1), NAPT (Many:1), and
1:1 Port Translation
■ NAT compatible SIP ALG
Secure Management
■ Multi-level access control
■ RADIUS AAA
■ TACACS+
■ SSH CLI and SSL GUI
■ Port Authentication (802.1x)
Content Filtering
■
Integration with Websense
Optional Virtual Private Network (VPN)
■ IPSec Tunnel Mode: 2,000 Tunnels
■ Encryption: DES, 3DES, and AES
■ Diffie Hellman Group Support:
❍ Group 1: MODP 768
❍
Group 2: MODP 1024
■
Hash Algorithms: MD5-HMAC and SHA1-HMAC
■ Authentication Mechanisms:
❍ XAUTH ❍ Secure ID
❍ X.509 Digital certificates ❍ DSS Signatures
❍ Preshared keys
■ Key Management: IKE (ISAKMP/Oakley)
■ Dead Peer Detection
■ NAT Traversal V2
Quality of Service (QoS)
■
Class-based Weighted Fair Queuing, Low Latency,
and Weighted Fair Queuing
■ DiffServ marking and packet recognition
■ Frame Relay Fragmentation
Multi-Slot Access Router Supporting up to 90 Mbps Worth of Bandwidth
Protocols
■ eBGP/iBGP ■ PPP
■ OSPF ■ PPPoE
■ RIP (v1 and v2) ■ PPPoA
■ Demand Routing ■ RFC 1483
■ GRE ■ Multilink PPP
■ IGMP v2 ■ HDLC
■ ATM (ADSL) ■ PPP Dial Backup
■
Frame Relay
■
PAP and CHAP
■ Multilink Frame Relay ■ Multihoming
■ PIM Sparse Mode ■ Layer 3 Backup
Frame Relay
■ Point-to-point
■ RFC 1490 Encapsulation
■ LMI types: LMI, ANSI (Annex D),
CCITT (Annex A) and Static
DHCP
■ Client, Server, and Relay
Administration
■ Familiar Command Line Interface (CLI)
■ Web-based GUI ■ SYSLOG logging
■ n-Command support ■ Email alerts (SMTP)
■ SNMP v3 ■ Policy statistics
Environment
■ Operating Temperature: 0° to 50 °C
■ Storage Temperature: -20° to 70 °C
■ Relative Humidity: Up to 95%, non-condensing
Physical
■ Chassis: 3U —13 cm H, 44.6 cm W, 26 cm D
■ Weight: 9.5 Kg
■ Power: 85-250 VAC, 50/60 Hz, 325 watts max.
Agency Approvals
■
FCC Part 68
■ Industry Canada CS03
■ UL & Canadian UL (CUL), IEC/EN, CSA
■ CE Mark
Ordering Information
Equipment Part #
NetVanta 5305 Chassis
with UK Power 4200990L1#UK
with Euro Power 4200990L1#EUR
with Australian Power 4200990L1#AUS
System with Enhanced Feature Pack
NetVanta 5305 Chassis with VPN
with UK Power Cord
4200990L2#UK
with Euro Power Cord 4200990L2#EUR
with Australian Power Cord 4200990L2#AUS
Enhanced Feature Pack VPN Upgrade 4200368L3
Redundant AC Power Supplies
UK Power Cord 4200840L1#UK
Euro Power Cord 4200840L1#EUR
Australian Power Cord 4200840L1#AUS
Modules
Octal T1/E1 Wide Module 1200843L1
HSSI Wide Module 1200934L1
T3 Wide Module 1200832L1
NetVanta 5305
ADTRAN, n-Command, and NetVanta are registered trademarks of ADTRAN, Inc. and/
or its affiliates in the U.S. and certain other countries. All other trademarks mentioned
in this document are the property of their respective owners. For more information
regarding ADTRAN's export license, please visit www.adtran.com/exportlicense
ADTRAN believes the information in this publication to be accurate as of publication
date, and is not responsible for error. Content subject to change without notice.
I-64200990L1-8G 14.1 November 2006
Copyright © 2006 ADTRAN, Inc.
All rights reserved.
