Introduction Introduction
The PosiTector PC Powder Checker is a hand-held, non-contact
Coating Thickness Gage that uses an airborne high frequency
ultrasound to analyze coating powder applied to rigid substrates to
calculate and display a predicted cured thickness.
The Gage consists of an Advanced body and a Powder Checker
(PC) probe that communicate with each other via wireless
technology. They must stay within 10 meters (30 feet) of each
other while measuring. A rubber holster with belt loop allows the
PosiTector body to stay with the operator while measuring.
This Quick Guide summarizes the basic functions of the Gage.
Download the full instruction manual at: www.defelsko.com/manuals
To preserve battery life, the PosiTector body and
PC probe power down after approximately 5 minutes of no activity.
All settings are retained.
1
1. POWER-UP both units (probe first).
a) Power-up probe by pressing the button.
b) Power-up PosiTector body by pressing the center
navigation button.
A beep and the letters “PC” will display on the upper left
corner of the PosiTector LCD. This indicates both units are
ready to measure.
2. ZERO the probe (pg 6)
3. ADJUST to the specific powder if necessary (pg 8)
4. MEASURE the applied powder (pg 2)
Quick Start Quick Start
NOTE:
