Avigilon Control Center System Integration Guide with AMAG Symmetry Security Management System
5
7. (Optional) If you would like to trigger an action when an alarm is acknowledged, select
the Activate selected digital output(s) on alarm acknowledgement check box.
a. Select the digital outputs to be activated and specify the duration.
b. Select the Require user confirmation before activating digital output check
box if users need to confirm the alarm before the digital output action is initiated.
c. Click Next.
8. Enter a Name for the alarm and set the alarm Priority. The alarm name is used to
identify the alarm during the integration.
9. Ensure the Enable Alarm check box is selected and click Finish.
Setting Up the Video Integration
Assigning Logical IDs to Cameras
In the Avigilon Control Center Client software, assign a logical ID to each camera. The SMS
software will only detect cameras with a logical ID. By default, cameras do not have a logical ID.
1. In the Avigilon Control Center Client software, right-click a camera in the System
Explorer and select Setup.
2. In the camera Setup dialog box, click General.
3. In the General settings dialog box, enter a Logical ID for the camera.
The logical ID must be unique number.
Adding Avigilon Recorder and Cameras to SMS
If you want to monitor Avigilon cameras in the SMS software, you must first add the Avigilon
server and cameras to the SMS system.
1. In the SMS software, select the Install tab then click Digital Video.
2. In the Install Video & Audio dialog box, select Avigilon Recorder then click New.
NOTE: The Avigilon Recorder option is only listed if you have the Avigilon AMAG Video
Integration installed on the SMS server.
