- 71 -
„
Username – username if the SMTP mail server requires authentication. Please
follow the Text Input method described in Section 4.1 to modify this item.
„
Password – password if the SMTP mail server requires authentication. Please
follow the Text Input method described in Section 4.1 to modify this item.
„
Mail From – the e-mail address of this DVR unit, i.e. the sender of the e-mails
originated from the triggered events. Please follow the Text Input method
described in
Section 4.1 to modify this item.
„
Mail To #1-5 – the receivers’ e-mail addresses. The system can send the e-mails
originated from the triggered events to up to 5 different receivers. Please follow
the Text Input method described in
Section 4.1 to modify these items.
„
Attachment – attached picture for the e-mail sent. The value could be (N/A,
Original picture, QCIF picture). Press +/- buttons to change this item.
6.10.2 FTP Setup
In Network Setup, press ENTER to call up FTP Setup as shown when the highlighted
option is FTP.
The FTP Setup allows the administrator to set FTP related parameters. When an
event occurs and FTP is enabled for the action, the recorded video/audio for that
event will be sent to the FTP server based on the parameters set here.
The general operations are as below:
„
▲▼ (Mouse: Left click)
Press these buttons to select the items.
„
ESC (Mouse: Right Click)
Press this button to escape from this screen, and return to Network Setup display.
If the Save dialog is shown, press ENTER to exit and save, ESC
(Mouse:
