#70705OPERATOR’SMANUAL 27
®
Part # Stock # Description Part # Stock # Description
1 70705-001 Handle 26 70705-026 Bearing6002
2 70705-002 Washer 27 70705-027 Gear
3 70705-003 SpringWasher 28 70705-028 CircleClip12
4 70705-004 ScrewST4x18 29 70705-029 NeedleBearing
5 70705-005 Switch 30 70705-030 BladeHousing
6 70705-006 WireHoldingBoard 31 70705-031 MiddleCover
7 70705-007 ScrewST4.2x14 33 70705-033 Bearing6200
8 70705-008 CordSleeve 34 70705-034 Armature
9 70705-009 PowerCord 35 70705-035 Bearing608
10 70705-010 ScrewM5x10 36 70705-036 WindshieldRing
11 70705-011 Washer 37 70705-037 Stator
12 70705-012 BladeGuard 38 70705-038 HandleGrip
13 70705-013 Spring 39 70705-039 MotorHousing
14 70705-014 Screw 40 70705-040 Screw
15 70705-015 LargeCover 41 70705-041 MotorCover
16 70705-016 NutM5 42 70705-042 CarbonBrushCover
17 70705-017 ArborBolt 43 70705-043 CarbonBrush
18 70705-018 OuterFlange 44 70705-044 ScrewM5x25
19 70705-019 Blade 45 70705-045 SpringWasher
20 70705-020 InnerFlange 46 70705-046 Washer
21 70705-021 Arbor 47 70705-047 Washer
22 70705-022 Key 48 70705-048 BoltM5x75
23 70705-023 Cover 50 70705-050 SpringWasher
24 70705-024 FrontCover 51 70705-051 Washer
25 70705-025 CircleClip15 52 70705-052 ScrewM5x18
PARTS LIST
