Detailed Hardware Functions
Power button Press and hold the power button for 3 seconds to turn
on/off the device.
Press power button once to save a waypoint manually
when device is active.
Mode Switch You can set up to 3 different interval modes for your
requirement by the software utility.
GPS status LED Flashing Green – GPS position is fixed.
Steady Green
– GPS position is not fixed.
Memory status LED Flashing Blue – Memory is 2/3 full.
Solid Blue – Memory is full.
Battery status LED Solid Red – Device is power on.
Flashing Red – Device is in low battery power.
Solid Amber – Battery is being charged.
External antenna Port For you to connect an external antenna.
USB connector Connect with the USB cable for data transfer or battery
charging purpose.
Belt clip You can use the belt clip to clip DG-100 on your belt or
backpack.
DC charger (optional) For you to charge the DG-100 in car or use it in car.
