DG-100 Setup
1. Turn on the power of DG-100, and
then connect it to the USB port on PC.
2. Check the COM port of DG-100 first.
Click [Start] > [Control Panel] >
[Performance and Maintenance]
> [System], you will see the System
Properties dialog box; click on
[Hardware] tab and then the
[Device Manager] button. Expand
the [Ports (COM & LPT)] item, and
the “Prolific USB-to-Serial Comm
Port” is the COM port of you DG-100.
3. Click from [Start] > [All Programs]
> [GlobalSat Data Logger] >
[DG-100 Utility] to start the
GlobalSat DG-100 utility.
The Configuration Wizard appears when the first
time you start the program. It helps you to quickly
setup the configuration with easy step by step.
y Step 1: Select Device Type. Please select
“Data Logger”.
y Step 2: Select COM port.
