Operating

Select suitable drill bit, insert the shank into the drill chuck as far

as possible and tighten chuck with key supplied making sure

that the shank of the device is securely clamped centrally

between the three chuck jaws. Remove chuck key.

When drilling holes of all sizes it is advised to use a pointed

punch to mark the centre at which the hole is to be drilled as

this will provide a starting point for the drill tip. This procedure

will prevent the drill bit from skidding, ensure that the hole is

drilled where intended and help to prevent drill breakage when

using small drills. When drilling, particularly with small diameter

drills, always try to ensure that load applied to the drill is such

that the drill bit is always at right angles to the hole being drilled.

Do not force the drill but allow it to cut.

When drilling always adopt a firm posture to be able to

counteract any sudden movement of the drill due to torque

reaction. Such torque reaction can occur when the drill stalls

due to a too heavy load being applied or the material being too

hard or tough. The torque reaction can occur when the drill

breaks through the material being drilled, particularly on sheet

metal. Always use eye protection and hand protection is

advised, particularly when drilling holes in metals where the

material being removed from the hole is in the form of long

sharp strips. Do not tie the drill chuck key to the drill as the

attaching device i.e. string or chain could become entangled

with the rotating chuck and bit etc.

If using an abrasive device, drilling stone or performing any

operation where dust is created, it is recommended to use a

breathing mask.

Always ensure that the material to be drilled is firmly fixed to

prevent its movement.

It is also recommended that when drilling holes of large

diameter to first pre drill a hole of smaller diameter as this will

reduce effort required to drill the hole and minimise torque

reaction.

Dismantling & Assembly Instructions

Disconnect from air supply

To remove the chuck (59) first open the chuck jaws with the key

provided and remove chuck screw (55) left hand thread. Place

chuck key securely into chuck and give the key a sharp tap so

as to unscrew a right hand thread. Grip motor housing (1) in a

vice with soft jaws on the flats at the rear end. Drive out pin (10)

and take off the throttle lever (9) Unscrew inlet bushing (3) With

a needle pointed tool, prise out deflector retainer (6) pull out

deflector (4) Unscrew 2 off screws (8) and take off body cap (7)

and gasket (11) Unscrew valve together with o-ring (13) and

reverse retainer (20) and take out spring (14) and pull out valve

pin (15) and o-ring (16)

Pull out reverse valve (23) Do not remove either of the brass

bushes in the motor housing (1) unless replacements are

required. If necessary reverse bush (18) can be taken out of the

motor housing (1) by first removing pin (22) With circlip pliers

remove retainer ring (52) and pull out spindle assembly. Remove

bevel gear (44) and key (49) Drive spindle (48) through bearing

(50) but do not remove grease plug (54) unless a replacement

is required.

Slacken lock ring (35) and then unscrew angle head (45) [left

hand thread] from main assembly. Take out gear drive assembly

and dismantle by pressing pinion gear (43) off bearing (42). Take

out planet gear with pins assembly (39) 3 off idler gears (37) and

internal gear (36) Pull out the motor assembly complete with

cylinder pin (32) from motor housing.

Grip the front end plate (33) by head and with a non metallic or

soft metal [lead or aluminium] hammer tap the splined end of

the rotor (30) to drive it through the front end plate (33) and

bearing (34) assembly. Tap out bearing (34) front end plate (33).

Remove cylinder (29) and take out five rotor blades (31) from

rotor (30) support rear end plate (28) in a piece of tube with a

diameter as close as possible to the maximum diameter of the

rotor and tap the non splined end of the rotor to drive it through

the rear end plate (28) and bearing (25)

Take out motor gasket (27) from motor housing (1)

Reassembly

Clean all component parts and examine for wear before

reassembling. Use only manufacturer or distributor supplied

parts.

Check in particular for wear on bevel gears, o-rings and rotor

blades.

Lightly coat all parts with a suitable pneumatic tool lubricating

oil, preferably one incorporating a rust inhibitor. Pack bearings

and grease gears and bevel gears with a lithium or molybdenum

based general purpose grease. Reassemble in the reverse order

taking note of the following:

1) When

fitting gasket (27) make sure that it does not cover

the ports and is positioned correctly.

2) Make

sure that the motor locating pin locates correctly in

the holes in the motor end plates and in the small hole

between the two ports at the bottom of the bore of the

motor housing

3) For

the motor assembly, ensure that the motor end plates

that abut the cylinder are flat and are free from burrs and

sharp edges. If necessary lap the faces on a fine grade of

abrasive paper laid on a flat surface.

pressing the trigger on the tool. Disconnect the air line and pour

into the intake bushing a teaspoonful (5ml) of a suitable

pneumatic motor lubricating oil preferably incorporating a rust

inhibitor. Reconnect tool to air supply and run tool slowly for a

few seconds to allow air to circulate the oil. If tool is used

frequently lubricate on daily basis and if tool starts to slow or

lose power.

It is recommended that the air pressure at the tool whilst the

tool is running is 90 p.s.i./6.3 bar. The tool can run at lower and

higher pressures with the maximum permitted working air

pressure of 100 p.s.i./7.0 bar.

Page No 2

Safety Rules When Using A Drill

1) Read all the instructions before using this tool. All operators

must be fully trained in its use and aware of these safety rules.

All service and repair must be carried out by trained personnel.

2) Always select a suitable cutting, abrasive device suitable for

use with this drill.

3) Always shut off the air supply to the drill and depress the

trigger to exhaust air from the feed hose before fitting, adjusting

or removing the device. Remove drill chuck.

4) Always adopt a firm footing and/or position and be aware of

torque reaction developed by the drill.

5) Use only correct spare parts.

6) Check hose and fittings regularly for wear. Do not carry the

tool by its hose and ensure that the hand is remote from the

on/off valve (trigger) when carrying the tool with air supply

connected.

7) Do not exceed maximum recommended air pressure. Avoid

low air pressures as this will allow the drill to stall more easily

and develop torque reaction.

8) Use safety equipment as recommended.

9) The tool is not electrically insulated. Do not use where there

is a possibility of coming into contact with live electricity, gas

pipes, water pipes, etc. Check the area of operation before

performing the operation.

10) Take care against entanglement of moving parts of the tool

with clothing, ties, hair, cleaning rags, etc. This will cause the

body to be moved towards the work process and can be very

dangerous.

11) Do not attempt to hold or guide the drill chuck when the tool

is running. Keep hands clear of the drilling process.
