Universal Air Tools UT616BN - Manual (Page 2)

Operating
Fit cutter as required. Cutter blades are covered with a plastic tube.
It is recommended to avoid cutting the hands and/or parts of the
body that this plastic tube is in place when fitting or removing the
cutter and when the tool is not in use.
When using the tool apply firm pressure and allow the tool to cut -
do not force the cutter. A spray of a diluted “washing up” liquid will
reduce friction and assist the cutting action by reducing friction.
The speed of the tool can be varied by installing an air regulator on
the airline.
Safety Rules for an Air Knife
1) Prolonged exposures to vibration can cause injury.
2) As this tool has a high vibration level, try to hold the tool when
running free for the shortest time period possible.
3) Read all instructions before using this tool. All operators must be
fully trained in its use and aware of these safety rules.
4) Do not exceed the maximum working air pressure.
5) Use personal protection equipment as recommended.
6) Use only compressed air at the recommended conditions.
7) If the tool appears to malfunction, remove from use immediately
and arrange for service and repair. If it is not practical to remove the
tool from service, then shut off the air supply to the tool and write or
have written a warning note and attach it to the tool.
8) If the tool is to be used with a balancer or other suspension device,
ensure that the tool is firmly attached to the suspension/support
device.
9) When operating the tool, always keep the body and particularly
the hands away from the working attachment fixed to the tool.
10) The tool is not electrically insulated. Never use the tool if there is
any chance of coming into contact with live electricity.
11) Always when using the tool, adopt a firm footing and/or position
and grip the tool sufficiently only to overcome any reaction forces
that may result from the tool doing work. Do not over grip.
12) Use only approved spare parts for maintenance and repair. Do
not modify or make temporary repairs. Major servicing and repairs
should only be carried out by persons trained to do so.
13) Do not lock, tape, wire, etc. the ‘On/Off’ valve in ‘On’ position.
The trigger lever, etc. must always be free to return to the ‘Off’
position when released.
14) Always shut off the air supply to the tool and press the ‘On/Off’
valve to exhaust the air from the feed hose before fitting, removing
or adjusting the working attachment fitted to the tool.
15) Before using the tool make sure that a shut off device has been
fitted to the supply line and the position is known and easily accessible
so that the supply to the tool can be shut off in an emergency.
16) Check hose and fittings regularly for wear.
17) Take care against entanglement of the moving parts of the tool
with clothing, hair, ties, cleaning rags, rings, jewellery, watches,
bracelets, etc. This could cause the body or parts of the body to be
drawn towards and in contact with the moving parts of the tool and
could be very dangerous.
18) It is expected that users will adopt safe working practices and
observe all local, regional or country legal requirements when
installing, using or maintaining the tool.
19) Take care that the exhaust air does not point towards any other
person or material or substance that could be contaminated by oil
droplets. When first lubricating a tool or if the tool exhaust has a high
oil content, do not allow the exhaust air to come near very hot
surfaces or flames.
20) Never lay the tool down until the working attachment has stopped
moving.
21) When the tool is not in use, shut off the air supply and press
trigger/lever to drain the supply line. If the tool is not to be used for
a period of time, first lubricate, disconnect from air supply and store
in a dry average room temperature environment.
22) If the tool is passed from one user to a new or inexperienced
user, make sure these instructions are available to be passed with
the tool.
23) Do not remove any manufacturer fitted safety devices where
fitted, i.e. wheel guards, safety trigger, speed governors, etc.
24) Where ever possible, secure workpiece with clamps, a vice, etc.
to make it rigid so it does not move during the work operation. Keep
good balance at all times. Do not stretch or overreach.
25) Try to match the tool to the work operation. Do not use a tool
that is too light or heavy for the work operation. If in doubt, seek
advice.
26) In general terms this tool is not suitable for underwater use or
use in explosive environments ) seek advice from manufacturer.
27) Try to make sure that the work area is clear to enable the work
task to be performed safely. If practical and possible, try to clear
unnecessary obstructions before starting work.
28) Always use air hose and couplings with minimum working
pressure ratings at least 11/2 times the maximum working pressure
rating of the tool.
Page No 2
Tool Maintenance
It shall be the tool owner’s and/or employer’s responsibility to assure
that tools are maintained in a safe operating condition. Tool
maintenance and repair shall be performed by authorised, trained,
competent personnel. Tools shall be disconnected from their
compressed air supply before repairs are attempted. Repairs shall be
consistent with the manufacturer’s recommended procedures. Tool,
hoses and fittings shall be replaced if unsuitable for safe operation. It
shall be the tool owner’s and/or employer’s responsibility to keep
required rating markings and warnings on the tool in legible condition.
