HARDwARE PACK
SHOwN FUll SIZE
NOT SHOwN FUll SIZE
Key
Qty.
Description
Key
Qty.
Description
40"
48"
A
2
2
Shoulder Bolt
B
2
2
Hex Bolt, 5/16" x 2" Lg.
C
2
2
Hex Bolt, 5/16" x 1-1/4" Lg.
D
15
15
Hex Bolt, 5/16" x 1" Lg.
E
4
4
Carriage Bolt, 5/16" x 1"
F
1
1
Hitch Pin, 3/8"
40"
48"
G
1
1
Hair Cotter Pin, 1/8"
H
2
2
Nylock Nut, 3/8"
I
23
23
Nylock Nut, 5/16"
J
4
4
Angle Bracket
K
1
1
Grip
A
B
C
D
E
F
G
H
I
J
K
ENGlISH
