REPAIR PARTS FOR 45-0457 DETHATCHER
REF
QTY
PART NO
DESCRIPTION
REF
QTY
PART NO
DESCRIPTION
1
1
66432
Tine Spring Shield
8
2
43070
Washer, 3/8”
2
10
46761
Spring
9
4
43081
Washer, 5/16”
3
2
41576
Hex Bolt, 3/8-16 x 1-3/4”
10
4
43407
Hex Bolt, 3/8-16 x 3/4”
4
2
48106
Shoulder Bolt, 3/8-16 x .9”
11
1
26600
Bracket, RH
5
8
HA21362
Nylock Nut, 3/8-16
12
1
26601
Bracket, LH
6
2
44798
Flange Bearing
1
40753-D
Owners Manual
7
2
24286
Spacer, .38 x .75 x 1”
PRINTED IN USA
FORM NO. 40753-D (11/03/08)
