REPAIR PARTS FOR MODEL 45-0343 DETHATCHER FOR SWEEPERS

REF

NO.

PART

NO.

QTY.

DESCRIPTION

REF.

NO.

PART

NO.

QTY.

DESCRIPTION

1

64650

1

Spring Mount Frame Assem.

12

R19171616

2

Washer, 1/2"

2

46761

7

Spring Tine

13

43019

1

Jam Nut, Plain 1/2-13

3

48098

1

Gauge Wheel

14

48115

1

Jam Nut, Nylock 1/2-13

4

43085

7

Hex Bolt, 5/16-18 x 1-1/2"

15

48813

2

U-Bolt, 1/4-20

5

43081

2

Washer, 5/16"

16

47189

4

Hex Nut, 1/4-20

6

43070

14

Washer, 3/8"

17

44481

2

Vinyl Cap

7

47810

7

Nylock Nut, 5/16-18

18

48811

2

Hook, Transport

8

48812

2

Clevis Pin, 5/16" x 1-3/8"

19

25054

2

Bracket, U-Bolt Clamp

9

47413

2

Clamp

48824

1

Owner's Manual

10

43055

2

Hair Cotter Pin, 3/32"

11

44025

1

Hex Bolt, 1/2-13 x 3-1/2"
