TINE DE-THATCHER REPAIR PARTS
MODEL NO’s. 45-0294 (40") & 45-0295 (48")
REF.
NO.
PART
NO.
QTY.
40" 48"
DESCRIPTION
REF.
NO.
PART
NO.
QTY.
40" 48"
DESCRIPTION
1
23442
3
3
Hitch Arm Mount Bracket
13
43082
2
2
Hex Lock Nut, 3/8-16
2
23981
2
2
Hitch Bracket
14
43070
10
12
Flat Washer, 3/8"
3
43783
10
12
Spring Tine
15
43182
15
15
Hex Bolt, 5/16" x 3/4"
4
47633
2
-
Spring Alignment Wire
16
43086
14
16
Lock washer 5/16"
47654
-
2
Spring Alignment Wire
17
43083
14
16
Hex Nut, 5/16-18
5
43021
2
2
Wheel
18
43064
19
19
Hex Lock Nut, 5/16-18
6
24593
1
-
Tine Shield (40")
19
44326
14
16
Carriage Bolt, 5/16" x 1"
24627
-
1
Tine Shield (48")
20
43943
1
1
Handle Grip
7
23914
2
2
Hitch Mount Arm
21
44180
2
2
Hex Bolt, 5/16-18 x 2"
8
24594
1
1
Lift Plate
22
43840
2
2
Hex Bolt, 5/16-18 x 1-1/4"
9
24595
1
1
Axle Bracket
23
47623
1
1
Hitch Pin, 3/8" (Flat Head)
10
24596
1
1
Lift Handle
24
43343
1
1
Hair Cotter Pin, 1/8"
11
43029
2
2
Shoulder Bolt
47634
1
1
Owner's Manual
12
23826
4
4
Angle Bracket
Purchase Common Hardware Locally
