2 3
SAFETY INFORMATION
TABLE OF CONTENTS
Please read and understand this entire manual before attempting to assemble, operate or install the product.
Inspect all materials before installation. If parts are damaged or missing, call 1-800-742-5044 before returning to
your retailer.
Safety Information ....................................2
Package Contents ....................................4
Specifications ...........................................4
Preparation ...............................................4
General Pump Uses .................................5
Dimensions ...............................................7
Location ofGrinder/Tank Unit ....................7
Toilet Assembly .........................................8
Water Supply Hookup ...............................9
Exposed Grinder/Tank Installation ..........11
Hidden Grinder/Tank Installation ............12
Piping......................................................13
Toilet Installation .....................................15
Adding Other Fixtures.............................18
Typical Installation ..................................19
Troubleshooting ......................................20
Warranty .................................................21
Replacement Parts .................................22
ELECTRICAL SHOCk HAzARD.
To help reduce the risk of electrical shock, a properly grounded receptacle or control box of
grounding type must be installed and protected by a ground fault circuit interrupter (GFCI) in
accordance with the National Electrical Code and applicable local codes. Never remove ground
pin from plug.
ELECTRICAL SHOCk HAzARD.
Make certain that the ground fault interrupter protected receptacle is within reach of the pump’s
power supply cord. DO NOT USE AN EXTENSION CORD. Extension cords that are too long
or too light do not deliver sufficient voltage to the pump motor. But more important, they could
present a safety hazard if the insulation were to become damaged or the connection end were to
fall into a damp or wet area.
ELECTRICAL SHOCk HAzARD.
Make sure the pump’s electrical supply circuit is equipped with fuses or circuit breakers of proper
capacity. A separate branch circuit, sized according to the National Electrical Code for the current
shown on the pump name plate is recommended (see Note 3).
ELECTRICAL SHOCk ALERT.
TESTING FOR GROUND. As a safety measure, each electrical outlet should be checked for
ground using an Underwriters Laboratory Listed circuit analyzer which will indicate if the power,
neutral and ground wires are correctly connected to your outlet. If they are not, call a qualified
licensed electrician.
ELECTRICAL SHOCk ALERT.
FOR YOUR PROTECTION ALWAYS DISCONNECT PUMP FROM ITS POWER SOURCE
BEFORE HANDLING. If pump is wired direct, de-energize the circuit at the control box. Grounded
pumps are supplied with a 3-prong grounded plug to help protect you against the possibility of
electrical shock. DO NOT UNDER ANY CIRCUMSTANCES REMOVE THE GROUND PIN. To
reduce the risk of electrical shock, a properly grounded receptacle of grounding type must be
installed and protected by a ground fault circuit interrupter (GFCI) in accordance with National
Electrical Code and applicable local codes.
ELECTRICAL SHOCk ALERT.
Installation and checking of electrical circuits and hardware should only be performed by a qualified
licensed electrician.
CHEMICAL ALERT.
According to the state of California (Prop 65), this product contains chemicals known to the state of
California to cause cancer and birth defects or other reproductive harm.
SAFETY INFORMATION
CAUTION
PRODUCT DAMAGE MAY RESULT
This unit is not designed to handle any material other than human waste and toilet paper. The following list
includes, but is not limited to, items that should not be used with this system: Feminine sanitary products,
condoms, cotton balls and swabs, baby wipes, paper towels, etc.
PRODUCT DAMAGE MAY RESULT
Check to be sure your power source is adequate to handle the amperage requirements of the motor as indicated
on the pump or unit I.D. tag.
PRODUCT DAMAGE MAY RESULT
All plumbing (discharge and vent lines) must be installed to meet local codes. Unit must be vented. Do not use
an automatic plumbing vent device. Toilet will not flush.
PRODUCT DAMAGE MAY RESULT
Maximum operating temperature for models S1201 / S1202 must not exceed 104°F (40°C). Duty cycle should
not exceed 30 seconds on/30 seconds off.
PRODUCT DAMAGE MAY RESULT
Do not use cleaning products containing bleach in the toilet tank, toilet or attached fixtures as they will degrade
the pump seals.
WARNING
WARNING
NOTES:
Repair and service should be performed by an Authorized Service Station only. (Consult Factory.)
Recommended for installations up to 20’ total dynamic head. Consult Factory if installation is above 15’ vertical
height in 1” pipe. Mini-grinder Pump is designed for use in PowerFlush Optima units only. It is not designed for use
in any other application.
Mini-grinder pump is rated for 115V, 60 Hz, 7 Amps, .5 HP.
Pumps with the “UL” mark and pumps with the “US” mark are tested to UL Standard UL778. CSA Certified pumps
are certified to CSA Standard C22.2 No. 108. PowerFlush Optima units only. It is not designed for use in any other
application.
Both S1201 and S1202 toilets utilize 1.28 gallons per flush.
All fixtures connecting to the system must be on the same floor level.
