sata qUICKpORt pRO lan
5. The user interface
A – Menu bar showing the entries “File“, “Options“, “View“ and “Help“
B – USB server with related IP address
C – USB devices connected to the USB server
D – “Search“ button: by left-clicking a search run is commenced, to detect devices connected to the USB server
E – “Open website“ button (only displayed when the USB-Server is selected): by left-clicking the USB server’s web
interface will be opened
F – “Connect device“ button (only displayed when a plugged USB device is selected): by left-clicking this button the
respective USB device is connected and locked for other users
Note:
The software will detect the connected USB server and associated devices automatically. Furthermore the USB server
supports automatic and manual IP address assignment; automatic address assignment via DHCP is selected by default.
In case your firewall prompts you during the installation process allow the USB server to access the respective network
resources.
5.1 uSB server and device status
The icons inside the user interface will already show the server’s and the device’s status.
5.1.1 Device free
The device is not locked and can be connected.
D E
A
B
c
F
