sata qUICKpORt pRO lan
4. Getting started
4.1 Hardware installation
Note:
Hard disk drive, card reader and USB front hub are accessed via USB while only the HDD may be addressed over eSATA.
This means that after connecting the device to your PC over USB and eSATA the HDD will be accessed via eSATA while the
card reader and the USB front hub are addressed over USB.
Using the SATA QuickPort Pro LAN in your network means that it can not be connected over eSATA or USB to a PC
simultaneously.
Therefore we suggest you to decide how you intend to use the device in advance to avoid further problems.
4.1.1 Local usage
1. Connect the included USB and/or eSATA cable to the according connectors of the SATA QuickPort Pro LAN and your PC.
2. Connect the included power adapter to the SATA QuickPort Pro LAN and a wall outlet.
3. Slide a 2.5" or 3.5" SATA HDD into the HDD slot of the device.
4. Insert a compatible memory card into the card reader and connect a maximum of two USB devices with the USB front hub
of the SATA QuickPort Pro LAN.
5. Switch on the device.
6. Your operating system will automatically recognize the connected devices.
4.1.2 Network usage
1. Connect the included patch cable to the network plug of the SATA QuickPort Pro LAN and an available network connector of
your switch/hub/router/PC or similar.
2. Connect the included power adapter to the SATA QuickPort Pro LAN and a wall outlet.
3. Install the included software.
4.2 Software installation (Windows for example)
1. Insert the included Tools CD into your CD/DVD drive.
2. Use the Windows Explorer to open the directory of the inserted Tools CD.
3. Double click (left mouse button) “Setup.exe”. The installation procedure will start.
Follow the installation wizard’s instructions.
4. To complete the installation you will be prompted to reboot your PC. Confirm this indication.
5. After successfully rebooting your system, the following icon will appear on your desktop:
Double-click (left mouse button) this icon to launch the software.
Note:
You need to install this server software on every PC from which you want to access the SATA QuickPort Pro LAN.
6. Slide a 2.5" or 3.5" SATA HDD into the HDD slot of the device.
7. Insert a compatible memory card into the card reader and connect a maximum of two USB devices with the USB front hob
of the SATA QuickPort Pro LAN.
8. Switch on the device.
