MAINTENANCE
MAINTENANCE SCHEDULE
Procedure Frequency
check lube clean change hours
Item
9 6 ‘ S 5
Reference Notes
Caster Wheel Plate
grease fittings
6 50
weekly
2 fittings: 1-top, 1-bottom
Caster Wheel Plate
gap
9 100
1/8 in (3 mm) max
tighten caster bolt if max exceeded
Rear Wheel Steering
grease fittings
6 25
25 hr or every 2 days
5 fittings: 1-top, 4, bottom
Wheel Hubs
main frame
6 100
100 hr or annually
re-pack bearings or 2 pumps grease
Wheel Hubs
wing
6 100
100 hr or annually
Wheel Hubs
packer wheel
6 100
100 hr or annually
Metering System
sprockets and chains
6 25
25 hr or every 2 days
use dry graphite lubricant
Seed/Fertilizer Knives
related components
9 10/100
10 hr or inspect daily, and,
100 hr or before seeding
Liquid Fertilizer (opt)
main filter screens
‘ 100
100 hr or before seeding, or,
between chemical changes
Liquid Fertilizer (opt)
basket filter(s)
‘ 50
50 hr, or, before seeding, or,
between chemical changes
Liquid Fertilizer (opt)
system flush
‘ 100
100 hr, or, before seeding, or,
between chemical changes
Liquid Fertilizer (opt)
nozzle bodies
‘
100
100 hr, or, before seeding, or,
between chemical changes
Metering Components
Seed Hawk
“
‘
100
100 hr, or, before seeding, or,
between product changes
Fan System
intake
9 ‘
10
10 hr or daily
remove accumulated debris
Fan System
fan blades
9 ‘ 10
10 hr or daily
must be intact and clean
Fill Auger System
8 in or 10 in
‘ 100
when changing between products,
or,
when stored for long periods of time
Fill Auger System
pillow block bearings
6 10/100
10 hr or daily, and,
100 hr or annually
Fill Auger System
universal joints
6 10/100
10 hr or daily, and,
100 hr or annually
Wings down
(if configured)
9 100
at end of seeding season, or,
when stored for long periods of time
Ball Lock Valves
open
9 100
at end of seeding season, or,
when stored for long periods of time
Tank Return Line
open - drain in pail
9 100
at end of seeding season, or,
when stored for long periods of time
Hydraulic Cartridges
flow control / relief
‘ 100
at end of seeding season, or,
when stored for long periods of time
Hydraulic Cylinders
cylinder seals
9 S A/R 10 / A/R
10 hr or daily - inspect
replace as required (A/R)
Tires
air pressure
9 10
10 hr or daily
inflate to proper pressure
