These red banded hoses are for your shank
lift and lower.
One hose has a ball valve to close for
transport and opened while seeding.
This single yellow banded hose is the dump line that is needed for the hydraulic
manifold.
The balls in each Pioneer hydraulic fitting has been removed. There is then no
restriction for the oil to return back to the tractor reservoir.
This line must be connected even when lowering the wings.
Seed Hawk Inc. recommends that this dump line has its own port into the
tractor’s reservoir.
These green banded hoses are for your wing lift
and lower.
When the wings are on the ground, the lever in the
cab is locked in the forward position while seed-
ing. This pressurizes the hydraulic manifold in
order to use the Seed Hawk Tool Bar successfully.
OPERATION
29
HYDRAULIC HOSE HOOK UP
