SPECIFICATIONS
TOOL BAR
Row
Spacing
Tool Bar Width
ft-in (m)
Number of
Seed Rows
Wing
Style
Folded Width
ft (m)
Folded Height
ft (m)
20’ 0” (6.1 m) 24 A 21’ 0” (6.4 m) Not applicable
25’ 0” (7.6 m) 30 B 16’ 9” (5.1 m) 10’ 0” (3.0 m)
30’ 0” (9.1 m) 36 C 20’ 3” (6.2 m) 10’ 0” (3.0 m)
35’ 0” (10.7 m) 42 C 20’ 3” (6.2 m) 12’ 3” (3.7 m)
40’ 0” (12.2 m) 48 C 20’ 3” (6.2 m) 14’ 9” (4.5 m)
45’ 0” (13.7 m) 54 D 20’ 7” (6.3 m) 15’ 8” (4.8 m)
48’ 4” (14.7 m) 58 D 20’ 7” (6.3 m) 15’ 8” (4.8 m)
50’ 0” (15.2 m) 60 E 20’ 7” (6.3 m) 17’ 0” (5.2 m)
53’ 4” (16.2 m) 64 E 25’ 1” (7.6 m) 17’ 4” (5.3 m)
55’ 0” (16.7 m) 66 E 25’ 1” (7.6 m) 17’ 4” (5.3 m)
60’ 0” (18.3 m) 72 E 25’ 1” (7.6 m) 17’ 4” (5.3 m)
65’ 0” (19.8 m) 78 E 25’ 1” (7.6m) 17’ 4” (5.3m)
71’ 8” (21.85 m) 86 F 28’ 4” (8.64m) 17’ 10”(5.45m)
80’ 0” (24.4 m) 96 F 28’ 4” (8.64m) 17’ 10”(5.45m)
83’ 4” (26.6 m) 100 F 28’ 8” (8.74m) 17’ 11”(5.46m)
10 in
(254
mm)
Legend
A - Fixed frame
B - Fixed 3-plex frame (floating wing option available for larger models)
C - Floating 3-plex frame/wing (front caster standard & rear caster std on large floating
wings
D - 5-plex (frame / 2 fixed wings / 2 floating wings - add floating wing opt for larger
fggf models)
E - 5-plex (frame / 4 floating wings - front and back tires on every wing)
F - 7-plex (frame / 6 floating wings – front and back tires on every wing)
DF - Dual front 11L15 caster wheels (11L15 rear tires on SH models)
18
