Seed Hawk
®
Manual Granular and Liquid Tanks Page 29
4.8 FAN(S)
Connect the pair of 3/4” hydraulic lines (Fan one has a blue band, fan two has a red
band) to supply the hydraulically driven fan motor. This tractor lever is locked in full
pressure position while seeding.
Some models are configured with a single fan while others may be configured with dual
fans. Fans are driven by hydraulic motors with speed controlled by the tractor hydraulic
flow system. Fan speed is indicated on the monitor panel in the cab.
Set fan speed to effectively transport the seed. Higher fan speeds will increase seed
bounce, and possibly damage the seed. Higher fan speeds also require more power
input from the tractor.
Typical fan speed ranges for various product types are listed below for reference:
PRODUCT FAN SPEED (rev/min)
Oilseeds 2000-3000
Cereals 2500-4000
Pulse Crops 3500-4200
Fertilizer (granular) 3500-4200
NOTE: Fan Speed is dependent on implement size and tractor hydraulic output.
NOTE: If tank is equipped with two fans, if one fan is not being used, it must be
ran at low rpm due to pressurization of meters.
4.9 CHECKING AIR AND PRODUCT FLOW
The test procedure outlined below serves as a guideline for ensuring proper fan speed
for effective delivery of product:
1. Remove hose(s) from an outside opener and temporarily attach to the frame of
the seeder with the hose looping no more than 12 in (300 mm) below the frame.
2. Begin seeding at normal field speed and observe distance product discharges
from hose(s) attached to the frame.
NOTE: All product should discharge within a range of 12 - 24 in (300 - 600 mm).
3. Adjust fan speed, if necessary, to ensure optimum air flow for product discharge.
