7/04 520-150-000 Models W09 & W15 Page 9
ITEM TOTAL
NO. PART NUMBER DESCRIPTION RQD.
39 807-042-115 Stud 16
40 210-008-330 Safety Clip 1
41 900-005-115 Washer, Lock 10
42 170-012-115 Capscrew, Hex Head 12
43 360-079-425 Gasket, Seat 4
44 360-080-425 Gasket, Flange (quautity of 8 with 4
Santoprene- see item 62 below)
45 670-043-110 Retainer, Flap Valve 4
46 807-044-115 Stud 8
47 170-018-115 Capscrew, Hex Head 10
48 545-008-110 Nut, Hex 8
49 807-018-110 Stud 8
50 547-002-110 Nut, Stop 8
51 334-020-000 Flange, Follower 4
52 360-021-000 Gasket 4
53 170-055-115 Capscrew, Hex Head 8
54 901-006-115 Flat Washer 40
55 807-078-330 Stud 2
56 196-128-010 Chamber, Outer 2
57 312-087-010 Elbow, Suction 2
58 312-086-010 Elbow, Discharge 2
59 518-112-010 Manifold 2
60 478-005-115 Locking Knob 44
61 338-011-357 Flap Valve 4
338-011-354 Flap Valve 4
338-008-360 Flap Valve 4
338-008-365 Flap Valve 4
62 570-002-360 Pad, Hinge 4
570-002-365 Pad, Hinge 4
901-035-115 Washer, Flat 8
(in place of hinge pad - for use with Santoprene only)
63 542-013-115 Stud Nut Assembly 8
64 980-004-115 Handle Yoke 4
65 807-077-115 Stud (Mounting Brkt.) 8
66 893-013-162 Shut-Off Valve 2
67 538-081-115 Pipe Nipple 2
73 807-081-118 Stud 12
W15-4 Unit Only
68
334-097-010 Flange, Adapter 2
69 807-005-115 Stud 8
70 900-007-115 Washer, Lock 8
71 545-009-110 Nut, Hex 8
72 360-036-426 Gasket, Flange 2
Not Shown:
535-037-000 Caution Plate 2
930-009-115 Handle Wrench 1
031-070-010 Main Air Valve Assembly 1
(Includes items 9,13,14,15,16,17,40)
1 Order item 10 in kit form only. Order 031-064-000 which also includes
items 5,7,8 & 12.
Repair Parts shown in bold face (darker)
type are more likely to need replacement
after extended periods of normal use.
They are readily available from most
Warren Rupp distributors. The pump
owner may prefer to maintain a limited
inventory of these parts in his own stock
to reduce repair downtime to a minimum.
IMPORTANT: When ordering repair parts
always furnish pump model number,
serial number and type number.
Delrin, Viton and Hytrel are registered tradenames of E.I.
DuPont.
Gylon is a registered tradename of Garlock. Inc.
Nylatron is a registered tradename of Polymer Corp.
Rulon II is a registered tradename of Dixion Industries
Corporation.
Hastelloy-C is a registered tradename of Cabot Corp.
Ryton is a registered tradename of Phillips Chemical
Company.
Valox is a registered tradename of General Electric
Company.
Kynar ® is a registered tradename of ATOFINA
Chemicals, Inc.
Warren Rupp, Rupplon, SANDPIPER, PortaPump,
Tranquilizer, and SludgeMaster are registered
tradenames of Warren Rupp Inc.
