7/04 520-150-000 Models W09 & W15 Page 8
1 070-006-170 Bearing, Sleeve 2
2 114-018-010 Bracket, Intermediate 1
3 560-023-360 O-Ring (Spool Pin) 2
4 135-016-162 Bushing, Threaded 2
5 620-011-114 Plunger, Actuator 2
7 360-041-379 Gasket, Valve Body 1
8 560-001-360 O-Ring 2
9 132-014-358 Bumper, Valve Spool 2
10 095-073-000 Assembly, Pilot Valve 1 1
10-A 095-070-551 Valve Body 1
10-B 755-025-000 Sleeve (without O-Ring) 1
10-C 560-033-360 O-Ring (Sleeve) 4
10-D 775-026-000 Spool (without O-Ring) 1
10-E 560-023-360 O-Ring (Spool) 2
10-F 675-037-080 Retaining Ring 1
11 165-066-010W Cap, End 2
12 360-048-425 Gasket, Valve Body 2 1
13 360-010-425 Gasket, End Cap 2
14 560-020-360 O-Ring 6
15 031-069-000 Sleeve & Spool Set 1
16 170-032-115 Capscrew, Hex Head 8
17 095-076-010 Body, Valve 1
18 196-129-015 Chamber, Inner 2
19 560-022-360 O-Ring 2
20 170-045-115 Capscrew, Hex Head 4
21 530-008-000 Muffler, Exhaust 1
22 685-041-120 Rod, Diaphragm 1
23 115-123-080 Bracket, Support 4
24 170-024-115 Capscrew, Hex Head 8
25 900-006-115 Washer, Lock 8
26 720-004-360 Seal, U-Cup 2
27 722-067-010 Seat, Flap Valve-Angle 4
28 115-124-080 Mounting Foot 2
29 132-026-000 Bumper, Diaphragm Plate 2
30 612-135-010 Plate, Outer Diaphragm Assembly 2
31 560-051-360 O-Ring (Clean-Out Cap) 4
32 612-133-010 Plate, Inner Diaphragm 2
33 286-059-365 Diaphragm 2
286-059-360 Diaphragm 2
286-059-354 Diaphragm 2
34 900-003-115 Washer, Lock 20
36 570-013-371 Wear Pad 2
37 165-062-010 Clean-Out Cap 4
38 200-055-015 Clean-Out Clamp Assembly 4
ITEM TOTAL
NO. PART NUMBER DESCRIPTION RQD.
Repair Parts shown in bold face (darker)
type are more likely to need replacement
after extended periods of normal use.
They are readily available from most
Warren Rupp distributors. The pump
owner may prefer to maintain a limited
inventory of these parts in his own stock
to reduce repair downtime to a minimum.
IMPORTANT: When ordering repair parts
always furnish pump model number,
serial number and type number.
000…Assembly sub assembly;
and some purchased items
010…Cast Iron
015…Ductile Iron
080…Carbon Steel AISI B-1112
100…Alloy 20
110…Alloy Type 316 Stainless Steel
112…Alloy “C”
114…303 Stainless Steel
115…301/302/304 Stainless Steel
120…416 Stainless Steel (Wrought Martensitic)
148…Hardcoat Anodized Aluminum
150…6061-T6 Aluminum
151…6063-T6 Aluminum
154…Almag 35 Aluminum
155 or 156…356-T6 Aluminum
157…Die Cast Aluminum Alloy #380
159…Anodized Aluminum
162…Brass Yellow Screw Machine Stock
170…Bronze Bearing Type Oil Impregnated
180…Copper Alloy
330…Plated Steel
331…Chrome Plated Steel
332…Electroless Nickel Plated
335…Galvanized Steel
356…Hytrel
357…Rupplon (Urethane Rubber)
360…Buna-N Rubber Color coded: RED
363…Viton (Fluorel) Color coded: YELLOW
364…E.P.D.M Rubber Color coded: BLUE
365…Neoprene Rubber Color coded: GREEN
366…Food Grade Nitrile Color coded: WHITE
375…Fluorinated Nitrile
379…Conductive Nitrile
405…Cellulose Fibre
408…Cork and Neoprene
425…Compressed Fibre
440…Vegetable Fibre
500…Delrin 500
501…Delrin 570
520…Injection Molded PVDF Natural Color
541…Nylon, glass filled
542…Nylon, unfilled
550…Polypropylene
551…Polypropylene, glass filled
552…Polypropylene, unfilled
555…PVC (Polyvinyl Chloride)
580…Ryton
600…PTFE (virgin material) Tetrafluoroethylene (TFE)
603…Blue Gylon
604…PTFE – Diaphragm
606…PTFE
610…PTFE Encapsulated Silicon
611…PTFE Encapsulated Viton
MATERIAL CODES
The Last 3 Digits of Part Number
1 Pilot Valve Body Assembly available in kit form. Order 031-064-000
which includes items 5,7,8 & 12.
2 Use gasket adhesive during assembly.
SERVICE AND OPERATING MANUAL
Model W15 Model W15 Model W15 Model W15 Model W15
Type 1
®
continued next page
