7/04 520-150-000 Models W09 & W15 Page 5
ITEM TOTAL
NO. PART NUMBER DESCRIPTION RQD.
1 070-006-170 Bearing, Sleeve 2
2 114-018-010 Bracket, Intermediate 1
3 720-004-360 Seal, U-Cup 2
4 135-016-162 Bushing, Threaded 2
5 620-011-114 Plunger, Actuator 2
6 095-073-000 Pilot Valve Body Assembly 1 1
6-A 095-070-551 Pilot Valve Body 1
6-B 755-025-000 Sleeve (With O-Ring) 1
6-C 560-033-360 O-Ring (Sleeve) 4
6-D 775-026-000 Spool (With O-Ring) 1
6-E 560-023-360 O-Ring (Spool) 2
6-F 675-037-080 Retaining Ring 1
7 360-041-379 Gasket, Valve Body 1
8 560-001-360 O-Ring (Actuator Plunger) 2
9 095-076-010 Body, Valve 1
10 132-014-358 Bumper, Valve Spool 2
11 165-066-010W Cap, End (Includes Item 55) 2
12 360-048-425 Gasket, Valve Body 2 1
13 360-010-425 Gasket, End Cap 2
14 560-020-360 O-Ring (Sleeve O.D.) 6
15 031-066-000 Sleeve & Spool Set 1
16 170-032-115 Capscrew, Hex Head 8
17 170-045-115 Capscrew, Hex Head 4
18 115-121-080 Mounting Foot, Left Hand 2
19 132-025-000 Bumper, Diaphragm 2
20 196-132-010 Chamber, Inner 2
21 196-131-010 Chamber, Outer 2
22 286-060-365 Diaphragm 2
286-060-360 Diaphragm 2
286-060-354 Diaphragm 2
23 560-022-360 O-Ring (Intermediate) 2
24 612-138-010 Plate, Diaphragm (Outer) 2
25 685-007-120 Rod, Diaphragm 1
27 170-024-115 Capscrew, Hex Head (Intermediate) 8
28 807-080-330 Stud (Outer Plate) 2
29 115-122-080 Mounting Foot, Right Hand 2
30 170-053-115 Hex Head Capscrew (Diaphr. Plate) 10
31 115-124-080 Mounting Foot 2
32 807-079-115 Stud, Inner (Chamber) 4
33 900-001-115 Washer, Lock (Inner/Outer Plate) 10
34 612-136-010 Plate, Diaphragm (Inner) 2
35 312-089-010 Elbow, Suction 2
36 312-091-010 Elbow, Discharge 2
37 338-010-357 Flap Valve 4
338-005-365 Flap Valve 4
Repair Parts shown in bold face (darker)
type are more likely to need replacement
after extended periods of normal use.
They are readily available from most
Warren Rupp distributors. The pump
owner may prefer to maintain a limited
inventory of these parts in his own stock
to reduce repair downtime to a minimum.
IMPORTANT: When ordering repair parts
always furnish pump model number,
serial number and type number.
MATERIAL CODES
The Last 3 Digits of Part Number
000…Assembly, sub-assembly;
and some purchased Items
010…Cast Iron
012…Powered Metal
015…Ductile Iron
020…Ferritic Malleable Iron
025…Music Wire
080…CarbonSteel AISI B-1112
100…Alloy 20
110…Alloy Type 316 Stainless Steel
111…Alloy Type 316 Stainless Steel (Electro Polished)
112…Alloy “C”
113…Alloy Type 316 Stainless Steel (Hand Polished)
114…303 Stainless Steel
115…302/304 Stainless Steel
117…440-C Stainless Steel (Martensitic)
120…416 Stainless Steel (Wrought Martensitic)
123…410 Stainless Steel (Wrought Martensitic)
148…Hardcoat Anodized Aluminum
149…2024-T4 Aluminum
150…6061-T6 Aluminum
151…6063-T6 Aluminum
152…2024-T4 Aluminum (2023-T351)
154…Almag 35 Aluminum
155 or 156…356-T6 Aluminum
157…Die Cast Aluminum Alloy #380
158…Aluminum Alloy SR-319
159…Anodized Aluminum
162…Brass, Yellow, Screw Machine Stock
165…Cast Bronze, 85-5-5-5
166…Bronze SAE 660
170…Bronze, Bearing Type, Oil Impregnated
180…Copper Alloy
310…Kynar
® Coated
330…Zinc Plated Steel
331…Chrome Plated Steel
332…Electroless Nickel Plated
335…Galvanized Steel
336…Zinc Plated Yellow Brass
337…Silver Plated Steel
340…Nickel Plated
342…Filled Nylon
354…Injection Molded #203-40 Santoprene- Duro 40D ± 5;
Color: RED
355…Thermoplastic Elastomer
356…Hytrel
357…Rupplon (Urethane Rubber) Color coded:PURPLE
358…Rupplon(UrethaneRubber)Color coded:PURPLE
(Some Applications, Compression Mold)
359…Urethane Rubber
360…Buna-N Rubber Color coded: RED
361…Buna-N
363…Viton (Fluorel) Color coded: YELLOW
364…E.P.D.M. Rubber Color coded: BLUE
365…Neoprene Rubber Color coded: GREEN
370…Butyl Rubber Color coded: BROWN
371…Philthane (Tuftane)
1 Pilot Valve Body Assembly available in kit form. Order 031-064-000
which includes items 5,7,8 & 12.
2 Use gasket adhesive during assembly.
SERVICE AND OPERATING MANUAL
Model W09 Model W09 Model W09 Model W09 Model W09
Type 1
®
List continued next page
