User Manual of 4-inch High Speed Dome
12
(year/month/day or hour/minute/second) of which you want to change the value.
(3) Click the up/down direction buttons to increase/decrease the value.
(4) Click IRIS+ button to confirm and exit.
Y - M - D 07 01 18
H - M - S 15 33 25
DONE: OPEN
QUIT: CLOSE
Figure 3-4 Set the System Time
Zero angle (initial position) configuration
Purpose:
You can define the initial position of the speed dome on the ZERO ANGLE submenu.
Steps:
1. Move the cursor to ZERO ANGLE using the direction buttons and click IRIS+ to enter.
2. Click the left/right/up/down direction buttons to adjust the view angle.
3. Click IRIS+ button to confirm and exit.
Fan parameter configuration
You can set the FAN CONTROL as TEMP, ON or OFF.
EIS (Electronic Image Stabilization) configuration
You can set the EIS FUNCTION as ON or OFF.
Note:
The selectable EIS levels vary depending on the camera models.
Preset direct focus
You can set the preset direct focus function ON/OF on PRESET DFOCUS submenu.
Protocol settings
You can set the PROTOCOL STATUS SET as ON or OFF, and set the PROTOCOL SET as AUTO MATCH,
PELCP-P, PELCO-D, Private-code, etc.
RS-485 checksum setting
You can set the 485CHECK SET as ON or AUTO for improving the controlling effect.
