Digital Video Recorder User Manual
37
Step4: click “apply” button to save the setting; click “exit” button to exit current interface.
Fig 4-30 network configuration-sub stream
4.6.3 Email
Step1: enter into system configurationnetwork configurationemail; refer to Fig 4-31:
SMTP Server/Port: the name and port number of SMTP server. After selecting
“This server requires a secure connection
(SSL) ”, user can setup mail servers (such as Gmail) according to actual needs.
Send address/password: sender ‟s email address/password
Send address/password: sender ‟s email address/password
Receive address: receiver ‟s email address. Here user can add at least three mail addresses.
Click TEST button to test the validity of the mailbox.
Parameter Meaning
FPS Range from: 1-25
Resolution Support CIF
Quality The higher the value is, the clearer the
record image. Six options: lowest,
lower, low, medium, higher and highest.
