Diagrams – Lincoln Electric IM586 STT-10 Head & Controls User Manual
Page 40
F-2
DIAGRAMS
F-2
STT-10
NOTE: This diagram is for reference only. It may not be accurate for all machines covered by this manual. The specific diag
ram for a particular code is pasted inside
the machine on one of the enclosure panels. If the diagram is illegible, write to the Service Department for a replacement. G
ive the equipment code number.
