A-2 INSTALLATION
INVERTEC® V100-S & V130-S
A-2
-20°C to +40°C -25°C to +55°C
INPUT Input Current
Voltage (2) at Rated Output Hertz
25A @ 130A OUTPUT
230V 19A @ 105A OUTPUT 50/60 Hz
16A @ 90A OUTPUT
Volts at
Duty Cycle (1) Amps Rated Amps
20% Duty Cycle 130 25.5
60% Duty Cycle 105 24.5
100% Duty Cycle 90 24
Welding Maximum Open
Current Range Circuit Voltage
3-130 Amps 67 VDC
INPUT
RECOMMENDED INPUT CABLE AND FUSE SIZES
OUTPUT FUSE (SUPERLAG) INPUT POWER EXTENSION EXTENSION
CURRENT OR BREAKER SIZE CURRENT CORD CORD CORD
RATING (up to 50 feet) (more than 50 feet)
130A 40A 25A 50 Amp, 250V, Three Conductor Three Conductor
Three-prong plug #6 AWG (13.0 mm 2 ) #4 AWG (20.7 mm 2 )
(NEMA Type 6-50P) or larger or larger
SINGLE PHASE
OPERATING TEMPERATURE STORAGE TEMPERATURE
RATED OUTPUT
(1) Based on a 10 min. period.
(2) Input voltage must be within ±10% of rated value.
Technical Specifications - Invertec V130-S
OUTPUT
Height Width Depth Weight
10.0 in. 5.4 in. 13.8 in. 11.0 lbs.
254 mm 138 mm 351 mm 5.0 Kg
PHYSICAL DIMENSIONS
