TROUBLESHOOTING
E-3
IDEALARC DC-600
If all recommended possible areas
of misadjustment have been
checked and the problem persists,
Contact your local Lincoln
Authorized Field Service Facility.
Observe Safety Guidelines
detailed in the beginning of this manual.
TROUBLESHOOTING GUIDE
PROBLEMS
(SYMPTOMS)
Major Physical or Electrical
Damage is Evident
The Machine is dead- The Input
contactor does not operate.
POSSIBLE AREAS OF
MISADJUSTMENT(S)
Contact the Lincoln Electric Service
Dept. (216) 383-2531 or 1-888-
935-3877
1. Check for blown or missing
fuses in input lines.
2. Check the three- phase input
line voltage at the machine.
The input voltage must match
the rating plate and reconnect
panel.
RECOMMENDED
COURSE OF ACTION
OUTPUT PROBLEMS
If for any reason you do not understand the test procedures or are unable to perform the tests/repairs safely, contact your
Local Lincoln Authorized Field Service Facility for technical troubleshooting assistance before you proceed.
