chapter 1 getting to know the basics

1-21

How to Enable S/PDIF Digital Output

The computer is equipped with an optical digital audio output

port called S/PDIF. You will need to connect the output port to

an external DTS, AC3, or PCM audio processor in your home
audio system via an optical digital audio cable (not supplied.)

To Enable S/PDIF output, do the following:

1. Double-click the speaker (audio) icon at the right hand
corner of the task bar.

2. The following box will appear. Put a check on S/PDIF

Output Enable to enable S/PDIF output port.

Note:

The S/PDIF port is located on the left bottom edge of the

computer. When you enable this port, all other audio functions will not

work. There will be no sound from the speakers or output in the audio

ports.
