29
Loading a Disc
¾ ¾ To play a CD disc, follow the instructions listed below.
¾ ¾ Push the CD-ROM/DVD-ROM/Combo Drive eject button on the
CD drive door. Gently pull the tray all the way out.
¾ ¾ Carefully lift the CD-ROM/DVD-ROM/Combo Drive by the
edges and make sure the shiny surface is face down (the side with
no writing on it).
Carefully insert the CD-ROM onto the tray. Push the CD-
ROM/DVD-ROM/Combo Drive down gently so that it snaps
onto the center ring.
¾ ¾ Push the tray back into the drive.
To remove a disk, do the following:
¾ ¾ Check the LED display and make sure that the computer is not
accessing the CD-ROM/DVD-ROM/Combo Drive.
¾ ¾ Push the eject button and pull the tray all the way out.
¾ ¾ Carefully pick up the CD disk by the edges and – while pressing
down on the center ring – remove the CD-ROM/DVD-
ROM/Combo from the tray.
Do not insert any foreign objects into the disc tray. If you
experience difficulty when ejecting the CD disk tray, stretch
a paper clip (or use a pin or a thin metal rod) and insert it
into the emergency eject hole located on the right side of
the front panel. The CD disk tray should eject immediately.
This procedure can also be used to remove a CD from the
drive when the Notebook is powered off.
PCMCIA Cards and Expansion Sockets
The Notebook features one PCMCIA expansion socket design to
interface with one Type II card.
Inserting a PCMCIA Card
The computer will emit a medium tone followed by a high tone when
a PC card is inserted. When you eject a card, the computer will emit a
high tone followed by a medium tone. You can insert and remove a
PC card whether the computer is turned On or Off.
Follow these instructions to insert a PCMCIA card:
1.
Hold the PCMCIA card with the arrow side up and the
connector side toward the socket.
